DfmExtractor

[jp-insert-download-block]

A small command line utility which allows you to extract DFM, LFM and FRM forms from executable files compiled by Delphi, Lazarus and CodeTyphon.

This program was made for my private use, but it may also be useful to someone.

When translating one program written in Delphi, I needed DFM forms to make it easier to work with the Poedit program, so I decided to write a small program to extract DFMs.

DfmExtractor version 1.1 [Win 32-bit] (2018.02.28)

Usage: DfmExtractor.exe -i=FILE [-n=NAME] [-idx=X] [-o=FILE] [-e=EXT] [-p=STR] [-a] [-d=DIR] [-l] [-h] [-V] [--home]

Mandatory arguments to long options are mandatory for short options too.
Options are case-sensitive. Options in square brackets are optional.

Input/output options

Switch	Description
-i, –input-file=FILE	An executable file containing Delphi, Lazarus or CodeTyphon forms (DFM, LFM, FRM).
-n, –form-name=NAME	Form name or form class name to extract.
-idx, –form-index=X	The index of the form to extract. Non-negative integer.
-o, –output-file=FILE	The output file with extracted form.
-e, –extension=EXT	The default extension of the output file(s). If not specified, DFM will be used.
-p, –prefix=STR	Output file(s) name prefix (for the -a option).
-a, –save-all	Saves all forms from the specified executable file to the given (or current) directory.
-d, –output-dir=DIR	Output directory (for the -a option).
-l, –list	Displays a list of all forms in the given input file.

Information

Switch	Description
-h, –help	Show this help.
-V, –version	Show application version.
–home	Opens program homepage in the default browser.

Example 1.

List all forms in the file AudioExtractor64.exe:

DfmExtractor.exe -i AudioExtractor64.exe -l

Result:

Forms: 10
Index |  Lines | Form name        | Form class
-------------------------------------------------------
    0 |    451 | CustomizeFrm     | TCustomizeFrm
    1 |    343 | FormAbout        | TFormAbout
    2 |     49 | FormCmdLine      | TFormCmdLine
    3 |    345 | FormErrors       | TFormErrors
    4 |  1 621 | FormFileInfo     | TFormFileInfo
    5 |    474 | FormListFileEdit | TFormListFileEdit
    6 |  6 035 | FormMain         | TFormMain
    7 |    790 | FormOptions      | TFormOptions
    8 |    422 | FormProgress     | TFormProgress
    9 |    169 | FormToolsInfo    | TFormToolsInfo

---

Example 2.

Save all forms from the AudioExtractor64.exe file to files with the LFM extension:

DfmExtractor.exe -i AudioExtractor64.exe -a -e lfm

Result:

File saved: CustomizeFrm.lfm
File saved: FormAbout.lfm
File saved: FormCmdLine.lfm
File saved: FormErrors.lfm
File saved: FormFileInfo.lfm
File saved: FormListFileEdit.lfm
File saved: FormMain.lfm
File saved: FormOptions.lfm
File saved: FormProgress.lfm
File saved: FormToolsInfo.lfm

---

Example 3.

Save form FormMain from the AudioExtractor64.exe file to main form.dfm file:

DfmExtractor.exe -i AudioExtractor64.exe -n FormMain -o "main form.dfm"

Result:

The form with name/class "FormMain" has been saved to file: main form.dfm

---

Example 4.

Save form with index 4 from the AudioExtractor64.exe file to a DFM file:

DfmExtractor.exe -i AudioExtractor64.exe -idx 4

Result:

The form with index 4 has been saved to file: FormFileInfo.dfm
